Yamaha XVS6501997 - Electrical

2-17
MAINTENANCE SPECIFICATIONS
SPEC
ELECTRICAL
Item
Standard Limit
Voltage: 12 V

Ignition system:
Ignition timing (B.T.D.C.)
Advancer type
12 at 1,200 r/min
TPS and electrical type


T.C.I.:
Pickup coil resistance/color
T.C.I. unit model/manufacturer
182  222 Ω at 20C/Gray – Black
J4T079/MITSUBISHI


Ignition coil:
Model/manufacturer
Minimum spark gap
Primary winding resistance
Secondary winding resistance
F6T541/MITSUBISHI
6 mm
3.8  4.6 Ω at 20C
10.1  15.1 kΩ at 20C




Spark plug cap:
Type
Resistance
Resin type
10 kΩ


Charging system:
Type
Model/manufacturer
Nominal output
Stator coil resistance/color
A.C. magneto
F4T459/MITSUBISHI
14 V 20 A at 5,000 r/min
0.50  0.62 Ω at 20C/White – White




Voltage regulator:
Type
Model/manufacturer
No load regulated voltage
Semi-conductor, short-circuit type
SH650A-12/SHINDENGEN
14.1  14.9 V



Rectifier:
Model/manufacturer
Capacity
Withstand voltage
SH650A-12/SHINDENGEN
25 A
240 V



Battery:
Specific gravity
1.320

Electric starter system:
Type
Starter motor:
Model/manufacturer
I.D.number
Output
Brush overall length
Commutator diameter
Mica undercut
Starter relay:
Model/manufacturer
Amperage rating
Constant mesh type
SM-13/MITSUBA
SM-13
0.7 kW
12.5 mm
28 mm
0.7 mm
MS-5F/JIDECO
100 A




4 mm
27 mm



