Yamaha XVS6501997 - Ac Magneto and Starter Clutch

4-49
20 Nm (2.0 m  kg)
80 Nm (8,0 m  kg)
Order Job name/Part name Q’ty Remarks
1
2
3
4
5
6
7
8
AC magneto and starter clutch
removal
Shaft
Starter idler gear
Bolts
Rotor
Woodruff key
Starter wheel gear
Washer
Starter clutch assembly
1
1
3
1
1
1
1
1
Remove the parts in the order below.
Refer to “AC MAGNETO
REMOVAL/INSTALLATION”.
Refer to “AC MAGNETO
INSTALLATION”.
For installation, reverse the removal
procedure.
AC MAGNETO AND STARTER CLUTCH
ENG
AC MAGNETO AND STARTER CLUTCH
