ELECTRIC STARTING SYSTEM
ELEC
NOTE:
EB802011
1. Fuses (main and ignition)
Refer to “SWITCH INSPECTION”.
Replace the fuses.
NO CONTINUITY
CONTINUITY
EB802012
2. Battery
S Check the battery condition.
Refer to “BATTERY INSPECTION” in
CHAPTER 3.
S Clean the battery terminals.
S Recharge or replace the battery.
INCORRECT
CORRECT
Open-circuit voltage:
12.8 V or more at 20_C
:
EB803020
TROUBLESHOOTING
IF THE STARTER MOTOR FAILS TO OPERATE:
Procedure
Check:
1. Fuses (main and ignition)
2. Battery
3. Starter motor
4. Relay unit (starting circuit cut-off relay)
5. Relay unit (diode)
6. Starter relay
7. Main switch
8. Engine stop switch
9. Neutral switch
10. Sidestand switch
11. Clutch switch
12. Start switch
13. Wiring connection (the entire starting
system)
D Remove the following part(s) before trouble-
shooting:
1) Battery cover
2) Rider’s seat
3) Fuel tank
4) Steering head side covers
D Use the following special tool(s) for trouble-
shooting.
Pocket tester:
90890-03112
