Yamaha XVS6501997 - Engine Mounting Bolts

4-6
Order Job name/Part name Q’ty Remarks
1
2
3
4
5
6
7
Engine mounting bolt removal
Engine stay (front-upper/left)
Engine stay (front-upper/right)
Cable holder
Engine stay (front-lower/left)
Engine stay (front-lower/right)
Engine mounting bolt (rear-upper/
left)
Engine mounting bolt (rear-upper/
right)
1
1
1
1
1
1
1
Remove the parts in the order below.
Place a suitable stand under the frame
and engine.
Securely support the motorcycle so
there is no danger of it falling over.
L=75 mm
L=60 mm
74 Nm (7.4 m  kg)
40 Nm (4.0 m  kg)
40 Nm (4.0 m  kg)
40 Nm (4.0 m  kg)
40 Nm (4.0 m  kg)
40 Nm (4.0 m  kg)
40 Nm (4.0 m  kg)
30 Nm (3.0 m  kg)
30 Nm (3.0 m  kg)
ENGINE REMOVAL
ENG
ENGINE MOUNTING BOLTS
