Yamaha XVS6501997 - Chassis

2-21
LUBRICATION POINTS AND LUBRICANT TYPES
SPEC
EB203010
CHASSIS
Lubrication point
Symbol
Steering head pipe (upper/lower), bearing
Steering head pipe, bearing cover lip
Steering head pipe, oil seal lip
Front wheel oil seal lip (right/left)
Rear wheel oil seal lip
Clutch hub fitting area
Rear brake pedal shaft
Shift pedal shaft
Sidestand bolt, sidestand sliding surface
Tube guide (throttle grip) inner surface
Brake lever pivot bolt, contact surface
Clutch lever pivot bolt, contact surface
Rear shock absorber (lower) oil seal lip
Swingarm pivot bearing inner surface
Swingarm pivot oil seal lip
