2-16
MAINTENANCE SPECIFICATIONS
SPEC
NOTE:
Part to be tightened
Thread size
Tightening
torque
Remarks
g
Nm mSkg
Passenger footrest and frame
Sidestand bracket and frame
Sidestand and sidestand bracket
Sidestand switch
Brake pedal/footrest and frame
Front wheel axle
Front wheel axle pinch bolt
Brake caliper
Brake disc and front wheel
Caliper bleed screw
Rear wheel axle nut
Tension bar and swingarm
Tension bar and brake shoe plate
Brake cam shaft lever
Clutch hub and damper
Final gear case (housing cover)
Bearing housing (final gear case)
Bearing housing (final gear case)
Bearing retainer (final drive pinion gear)
Oil filter bolt (final gear)
Oil drain bolt (final gear)
Housing cover
M8
M10
M10
M5
M6
M16
M8
M10
M8
M7
M14
M8
M8
M6
M10
M10
M8
M10
M65
M14
M14
M10
26
64
56
4
64
59
20
40
23
6
97
20
20
10
62
18
23
23
115
23
23
42
2.6
6.4
5.6
0.4
6.4
5.9
2.0
4.0
2.3
0.6
9.7
2.0
2.0
1.0
6.2
1.8
2.3
2.3
11.5
2.3
2.3
4.2
LH thread
1. First, tighten the ring nut approximately 52 Nm (5.2 mSkg) by using the torque wrench, then loosen
the ring nut completely.
2. Retighten the ring nut to specification.
