1-6
SPECIAL TOOLS
GEN
INFO
Tool No. Tool name/How to use Illustration
90890-01701
Sheave holder
This tool is needed to hold the rotor
when removing or installing the rotor
bolt.
90890-03081
Compression gauge set
These tools are needed to measure
engine compression.
90890-03094
Vacuum gauge
This gauge is needed for carburetor
synchronization.
90890-03112
Pocket tester
This instrument is needed for checking
the electrical system.
90890-03113
Engine tachometer
This tool is needed for observing
engine rpm.
90890-03141
Timing light
This tool is necessary for checking
ignition timing.
90890-04018
Valve guide remover & installer
This tool is needed to remove and
install the valve guide.
90890-04019
Valve spring compressor
This tool is needed to remove and
install the valve assemblies.
90890-04050
Bearing retainer wrench
This tool is needed when removing or
installing the final drive shaft bearing.
