Yamaha XVS6501997 - Page 232

6-32
FRONT FORK
CHAS
Order Job name/Part name Q’ty Remarks
12
13
14
15
16
Seal spacer
Slide metal
Inner tube/piston metal
Oil lock piece
Outer tube
1
1
1/1
1
1
For assembly, reverse the disassembly
procedure.
Refer to “FRONT FORK ASSEMBLY”.
23 Nm (2.3 m  kg)
30 Nm (3.0 m  kg)
