6-44
Order Job name/Part name Q’ty Remarks
8
9
10
11
12
13
14
Rubber washer
Lower ring nut
Bearing cover
Lower bracket
Bearing (upper)
Rubber seal
Bearing (lower)
1
1
1
1
1
1
1
Refer to “STEERING HEAD
REMOVAL/INSTALLATION”.
For installation, reverse the removal
procedure.
52 Nm (5.2 m  kg)
18 Nm (1.8 m  kg)
110 Nm (11.0 m  kg)
32 Nm (3.2 m  kg)
STEERING HEAD
CHAS
