7-26
:
3. Main switch
Refer to “SWITCH INSPECTION”.
INCORRECT
Replace main switch.
CORRECT
4. Lights switch
Lights switch is faulty, replace handlebar
switch (right).
5. Dimmer switch
Refer to “SWITCH INSPECTION”.
INCORRECT
Dimmer switch is faulty, replace handlebar
switch (left).
CORRECT
6. Pass switch
Refer to “SWITCH INSPECTION”.
INCORRECT
Pass switch is faulty, replace handlebar
switch (left).
CORRECT
EB805013
7. Wiring connection
S Check the connections of the entire lighting
system.
Refer to “WIRING DIAGRAM”.
POOR CONNECTION
Properly connect the lighting system.
CORRECT
Check the condition of each of the lighting
system’s circuits.
Refer to “LIGHTING SYSTEM CHECK”.
Refer to “SWITCH INSPECTION”.
CORRECT
LIGHTING SYSTEM
ELEC
