Yamaha XVS6501997 - Page 32

2-12
MAINTENANCE SPECIFICATIONS
SPEC
Part to be tightened Part name
Thread
size
Q’ty
Tightening
torque
Remarks
g
size
y
Nm mSkg
Clutch spring
Clutch adjuster
Clutch boss
Push lever axle
Middle drive pinion gear
Bearing retainer (middle driven
shaft)
Yoke (middle driven shaft)
Bearing housing (middle drive
shaft)
Shift lever stopper
Shift pedal link
Shift pedal adjuster
Stator coil
Pickup coil
Bolt
Nut
Nut
Screw
Nut
—
Nut
Bolt
Bolt
Bolt
Nut
Screw
Screw
M6
M6
M20
M8
M20
M65
M14
M8
M8
M6
M6
M6
M6
5
1
1
1
1
1
1
4
1
1
2
3
3
8
8
70
12
120
110
90
25
22
10
7
7
7
0.8
0.8
7.0
1.2
12.0
11.0
9.0
2.5
2.2
1.0
0.7
0.7
0.7
Use lock washer
Stake
Use lock washer
1 of 2 has LH
thread
