Yamaha XVS6501997 - Page 34

2-14
MAINTENANCE SPECIFICATIONS
SPEC
Item Standard Limit
Master cylinder inside diameter
Caliper cylinder inside diameter
Caliper cylinder inside diameter
Brake fluid type
12.7 mm
30.1 mm
33.3 mm
DOT 4
SSS
SSS
SSS
SSS
Rear brake:
Type
Brake drum inside diameter
Lining thickness
Shoe spring free length
Leading, trailing
200 mm
4 mm
68 mm
SSS
201 mm
2 mm
SSS
Brake lever & brake pedal:
Brake lever free play (at pivot)
Brake lever free play (at lever end)
Brake pedal position
Brake pedal free play
Clutch lever free play (at pivot)
Clutch lever free play (at lever
end)
1 X 2 mm
10 X 15 mm
85 m
20 X 30 mm
2 X 3 mm
10 X 15 mm
SSS
SSS
SSS
SSS
SSS
SSS
