6.3 Module Specifications
6-7
6
6.3 Module Specifications
This section explains the 217IF Module specifications.
6.3.1 Hardware Specifications
6.3.2 Communications Specifications
The following table shows the communications specifications for the 217IF Module.
* The maximum baud rate of the RS-422/485 (CN3) depends on the CN1
and CN2 baud rates. If 19.2 kbps is set for CN1 and CN2, then the maxi-
mum transmission speed for CN3 will be 19.2 kbps.
Item Specifications
Name 217IF Communications Module (Serial Communications
Module)
Model JEPMC-CM200
Description 217IF
Dimensions 40 × 130 × 105 mm (W × H × D)
(Size for one option slot of MP920)
Approximate Mass Base: 200 g, Case: 165 g
Power Supply Supplied from Base Module
+5 V, 300 mA
Table 6.3 217IF Module Communications Specifications
Item Specifications
Interface RS-232C: Two lines
RS-422/485: One line
Connector RS-232C (CN1): D-sub 9-pin (female)
RS-232C (CN2): D-sub 9-pin (female)
RS-422/485 (CN3): MR-8 (female)
Transmission Distance RS-232C: 15 m max.
RS-422/485: 300 m max.
Transmission Speed RS-232C (CN1/CN2): 300 bps to 19.2 kbps
RS-422/485 (CN3): 2400 bps to 76.8 kbps
*
(300/600/1200/2400/4800/9600/14400/19200/28800/38400/
48000/ 57600/64000/76800 bps)
Access Method Non-synchronous (start-stop synchronization)
Communications Mode Message communications, engineering communications
Communications Protocol MEMOBUS (Master/Slave), MELSEC Communications,
OMRON Communications
Connection Configuration RS-232C: 1:1
RS-422: 1:1
RS-485: 1:N
Transmission Format
(Can be Set)
Data bit length: 7 or 8 bits
Stop bits: 1 or 2 bits
Parity bit: Even/Odd/None
