YASKAWA MP920 - 217 IF Transmission Settings

8.1 Connection to a Display Device
8-7
8
CN3 Cables
Note: Connect the cable so that the terminating resistance for 217IF Module
is connected.
8.1.3 217IF Transmission Settings
The following figure shows the 217IF Transmission settings.
217IF GP
MR 8-pin D-sub 25-pin
Signal Name Pin No. Pin No. Signal Name
RXR
41
FG
RX（-）
17
SG
RX（+）
29
TXR
510
RD A
TX（-）
611
SD A
TX（+）
715
SD B
SG
816
RD B
SH
318
19
21
22
Shield
FG
