YASKAWA MP920 - Temperature Controller Settings

8.4 Connection to a Temperature Controller
8-27
8
8.4.4 Temperature Controller Settings
The following table shows the switch settings for the SR-Mini Temperature Controller.
Bit 1 OFF
Always OFF
Bit 2 OFF
Always OFF
Bit 3 ON
Set according to the transmission speed
Bit 4 ON
Set according to the transmission speed
Bit 3 Bit 4 Transmission Speed
OFF OFF
2,400 bps
OFF ON
4,800 bps
ON OFF
9,600 bps (factory default setting)
ON ON
19,200 bps
