Appendix D Wiring Communications
D.5.3 CP-215 Repeater Transmission Line Components
D-28
D.5.3 CP-215 Repeater Transmission Line Components
CP-215 Repeater-TT Transmission Line Components
Cables
* 1. Refer to the Manufacturing Specifications No. II-95J6015.
* 2. Refer to the Manufacturing Specifications No. II-95J6015.
* 3. Pas4 refers to cable signal dB loss at 4 MHz. Z4 refers to cable charac-
teristic impedance at 4 MHz.
Note: Specify the desired model and cable length (in 500-m units) when
ordering.
Connectors
Junction Boxes
Terminating Resistors
Note: Use junction terminal blocks to install terminating resistors.
Name Model Electrical
Product Code
Specifications Usage Manufacturer
Twisted-pair
Cable
YS-IPEV-SB
*1
,
1P × 0.3 mm
2
Pas4: 60 dB/km
Z4: 75
For in-panel low-voltage
ducts
Fujikura Corpo-
ration
YS-IPEV-S
(Cu)
*2
,
1P × 1.25 mm
2
Pas4: 22 dB/km
Z4: 77
For panel-to-panel low-
voltage ducts
Fujikura Corpo-
ration
Name Model Electrical
Product Code
Specifications Usage Manufacturer
MR-8
Connector
MR-8LM(G)
8-pin, male, case
included
For connection and
branching of CP-215
Repeater.
One connector required
for each Repeater.
Honda Commu-
nication Indus-
tries Co., Ltd.
Name Model Electrical
Product Code
Specifications Usage Manufacturer
JC215-01
87215-8100x For cable size conver-
sion
For conversion of in-
panel or panel-to-panel
cable size.
Two junction boxes
required for each control
panel.
YAS KAWA
ELECTRIC
CORPORA-
TION
Name Model Electrical
Product Code
Specifications Usage Manufacturer
Terminating
Resistors
ERO-
SICKF75R0
R002849 75±1%, 1/2 W, 100
PPmC
Mounted at both ends of
transmission line.
Two resistors required
for each transmission
line.
YAS KAWA
ELECTRIC
CORPORA-
TION
