8 Example Communications Module Applications
8.4.3 217IF Transmission Settings
8-26
Note: Connect the cable so that the terminating resistance for the 217IF is
connected.
Refer to 8.1.2 Cable Specifications for the MPE720 Programming Device connections.
8.4.3 217IF Transmission Settings
The following figure shows the 217IF Transmission settings.
217IF SR-Mini
MR 8-pin Modular (6-pin)
Signal Name Pin No. Pin No. Signal Name
RXR
41
R (A)
RX (-)
12
R (B)
RX (+)
23
SG
TXR
54
T (B)
TX (-)
65
T (A)
TX (+)
76
FG
SG
8
SH
3
Shield
FG
RS485
INFO
