7.4 Cables
7-11
7
7.4 Cables
This section explains the cable specifications for communications using the 218IFA Module.
7.4.1 218IF Connection Cables
218IF Connector Pin Layout (CN1/AUI)
The 218IFA Ethernet port is a 10Base-T communications port.
The connector for this port is RJ-45 (Modular Jack).
The following table shows the pins, layout, and signal names of the 218IFA Ethernet con-
nectors.
Table 7.3 218IFA 10Base-T Connector (CN1)
No. Signal Name Remarks No. Signal Name Remarks
1 TXD+ Send data (+) 5 N.C. Not connected
2 TXD- Send data (-) 6 RXD- Receive Data (-)
3 RXD+ Receive Data (+) 7 N.C. Not connected
4 N.C. Not connected 8 N.C. Not connected
