5.7.8 CP-215 Repeater-TS5
The CP-215 Repeater-TS5 is an optical Repeater that relays CP-215 or CP-216 transmission
signals using crystal glass optical fiber cables.
There are two models of CP-215 Repeater-TS5.
• 24-VDC model
• 100/115-VAC, 200ñVAC, 100-VDC model
The transmission distance can be extended to a maximum of 5 km.
Item Specifications
Transmission Speed 1 Mbps, 2 Mbps, 4 Mbps (can be set with SW1)
Transmission Distance
*
0 to 2 km
Optical Fiber Crystal glass optical fiber, GI-50/125, wavelength λ = 850 nm,
loss = 3 dB/km or less, bandwidth = 200 MHz
⋅ km
Applicable Connector FC (conforming to JIS C 5970 F01)
Optical Transmission
Level (CN4)
-18 dBm
Optical Reception Level
(CN3)
-15 to -28 dBm
