A.1 SEND MESSAGE Function (MSG-SND)
A-3
A
A.1.2 Parameter List (PARAM)
PARAM is one of the inputs and has a parameter list structure consisting of 17 words. The
value in PARAM is the leading address of MW, DW, or #W registers.
The parameters are shown below. No setting is required for the parameters that are blank in
the “No-protocol” column.
* PARAM00 is the leading address.
PARAM
No.
IN/
OUT
Contents Remarks
MEMOBUS No-protocol
00
*
OUT Processing result Processing result
01 OUT Status Status
02 IN Remote station number Remote station num-
ber
Connection number
when DEV-TYP is set to
CP-218.
03 SYS Reserved by system. Reserved by system.
04 IN Function code
05 IN Data address Data address
06 IN Data size Data size
07 IN Remote CPU number Remote CPU number
08 IN Coil offset
09 IN Input relay offset
10 IN Input register offset
11 IN Holding register offset Register offset
12 SYS For system use For system use
13 SYS Reserved by system. Reserved by system.
14 SYS Reserved by system. Reserved by system.
15 SYS Reserved by system. Reserved by system.
16 SYS Reserved by system. Reserved by system.
