5 215IF Module
5.7.2 System Configuration
5-38
5.7.2 System Configuration
Standard System Configuration
The standard system configuration for an Electrical Repeater is shown below.
System Configuration for Electrical Repeater-TT
The following example shows the standard system configuration using one Electrical
Repeater. In this example, an Electrical Repeater-TT is connected between the main bus and
branch bus in order to connect 60 stations.
Fig. 5.6 System Configuration for Electrical Repeater-TT
Station
CP-215 main bus
170 m max. per 30 stations
Electrical Repeater
-TT
170 m max. per 30 stations
CP-215 branch bus
CN3
CN1
Station
Station Station
