6 217IF Module
6.5.5 Saving CP-217 Transmission Definitions Data
6-20
6.5.5 Saving CP-217 Transmission Definitions Data
Use the following procedure to save the CP-217 Transmission Definitions data settings.
In online mode, the settings are saved in the Machine Controller and the computer’s hard
disk.
In offline mode, the settings are saved on the computer’s hard disk.
1. Click File (F
) and then Save (S) on the CP-217 Transmission Definition Window’s
menu.
2. Verify the message in the message box and click the Y
es button.
3. Verify the message in the message box and click the OK button.
6.5.6 Deleting CP-217 Transmission Definitions Data
Use the following procedure to delete all of the CP-217 Transmission Definitions data set-
tings.
In online mode, the data will be deleted from the Machine Controller and the computer’s
hard disk. In offline mode, the data will be deleted from the computer’s hard disk.
1. Click File (F
) and then Delete (D) on the CP-217 Transmission Definition Window’s
menu.
2. Verify the message in the message box and click Y
es to delete the data.
When the Delete operation is executed, the CP-217 Transmission Definitions data settings for all 3 cir-
cuits will be deleted.
Table 6.6 Leading Register Numbers and Number of Words
Setting Machine Controller
MP920
CP-316
CP-316H CP-916A CP-916G RIO-05
Input Relay Read Head REG (Leading Register) IW0000 IW0000 IW0000 IW0000 IW0000 IW0000
WD Size (Number of Words) 5120 6400 6400 2304 2304 2304
Input Register
Read
Head REG (Leading Register) IW0000 IW0000 IW0000 IW0000 IW0000 IW0000
WD Size (Number of Words) 5120 6400 6400 2304 2304 2304
Coil Read/Write Head REG (Leading Register) MW00000 MW00000 MW00000 MW00000 MW00000 MW00000
WD Size (Number of Words) 32768 8192 16384 3072 3072 3072
Holding Register
Read/Write
Head REG (Leading Register) MW00000 MW00000 MW00000 MW00000 MW00000 MW00000
WD Size (Number of Words) 32768 8192 16384 3072 3072 3072
INFO
To Next Page
