D.6 Optical Cable Specifications
D.6.1 H-PCF Cable Specifications
* Temporary tension applied when the cable is laid. The maxim allowable
tension that can be applied to the neck of the optical connector is 2 kg.
The applicable optical connector is JIS C 5977 F08 type.
Item Specifications
Cable Type Two-core cord Indoor reinforced
cable
Indoor cord
assembly cable
Outdoor LAP
sheathed cable
Representative Model HCB1-CD202-43-
V
HCB2-CL202-
43V8V
HCB6-CL202-
43V13V
HCB6-LL202-
43V15V
Optical Fiber Type Plastic clad multi-mode optical fiber (manufactured by Toray Industries Inc., H-
PCF, SI type, HCU-FB200-L)
Transmission Loss 7 dB/km max. at wavelength λ = 850 nm (ambient temperature: 25°C)
Core and Clad Material: Crystal glass, Diameter: 200 ±5 µm
Material: Acrylate resin fluoride, Diameter: 230 + 0, -10 µm
Numerical Aperture (NA) 0.37
Transmission Bandwidth 14.5 MHz at λ = 850 nm
Number of Cores 2
Tension Member None Material: Steel cable with plastic sheath
Outer diameter: 2.4 mm
Sheath Orange heat-
resisting PVC
Orange heat-
resisting PVC
sheath
Black heat-resist-
ing PVC sheath
Black LAP sheath
Finished Outer Diameter 4.3 mm 8.4 mm 13.7 mm 15.1 mm
Approximate Mass 15 kg/km 50 kg/km 150 kg/km 170 kg/km
Storage
Temperature
Maximum 70°C70°C70°C70°C
Minimum -40°C-40°C-40°C-40°C
Operating
Temperature
Maximum 60°C60°C60°C60°C
Minimum -10°C-10°C-10°C-10°C
Maximum Allowable
Tension
*
20 kg 30 kg 75 kg 75 kg
Allowable
Bending
Radius
Temporary
Bending (No
Load)
15 mm 25 mm 50 mm 50 mm
Long-term
Bending (No
Load)
45 mm 50 mm 100 mm 100 mm
Maximum Allowable
Temporary Lateral Pressure
None 50 kg/50 mm 100 kg/50 mm 100 kg/50 mm
