6.5 CP-217 Transmission Definitions
6-17
6
6.5.4 Setting CP-217 Transmission Definitions Data
This section explains the various parameters required to use the CP-217 transmission sys-
tem.
The CP-217 has tabs for the current circuit and the next two circuits. Click another circuit’s
tab to switch to that circuit’s Transmission Parameters Window.
CP-217 Transmission Definitions
1. Configuration Information
Displays the CP-217 configuration information that was set in the Module Definition
Window.
• Rack#: Displays the rack number of the rack in which the CP-217 is defined.
• Slot#: Displays the slot number of the slot in which the CP-217 is defined.
2. CIR# (Circuit Numbers)
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
18.
17.
