A.2.2 Parameter Lists (PARAM)
A-14
A.2.2 Parameter Lists (PARAM)
PARAM is one of the inputs and has a parameter list structure consisting of 17 words. The
value in PARAM is the leading address of a MW, DW, or #W register.
The parameters are shown below. No setting is required for the parameters that are blank in
the “No-protocol” column.
* 1. PARAM00 is the leading address.
* 2. “IN” when DEV-TYP is set to CP-218.
PARAM
No.
IN/
OUT
Contents Remarks
MEMOBUS No-protocol
00
*
OUT Processing result Processing result
01 OUT Status Status
02 OUT
*2
Remote station number Remote station num-
ber
Remote connection num-
ber when DEV-TYPE is
set to CP-218.
03 SYS Reserved by system. Reserved by system.
04 OUT Function code
05 OUT Data address Data address
06 OUT Data size Data size
07 OUT Remote CPU number Remote CPU number
08 IN Coil offset
09 IN Input relay offset
10 IN Input register offset
11 IN Holding register offset Register offset
12 IN
Write range LO
Register offset
13 SYS
Write range HI
Register offset
14 SYS Reserved by system. Reserved by system.
15 SYS Reserved by system. Reserved by system.
16 SYS Reserved by system. Reserved by system.
