5.7 CP-215 Repeaters
This section describes CP-215 Repeaters.
5.7.1 CP-215 Repeaters
CP-215 Repeaters are used to extend the CP-215 transmission distance. Different CP-215
Repeater models are available for use with twisted-pair, coaxial, and optical fiber cables.
The best system can be constructed according to the transmission distance.
For applicable cables and other installation details, refer to the appendixes and the FDS Sys-
tem Installation Manual.
Table 5.4 CP-215 Repeaters
Name Product Code Details
CP-215 Repeater-TT 87215-1100 Repeater between twisted-pair cables
(Power supply: 24 VDC)
CP-215 Repeater-TT
(100 VAC, 200 VAC, 100
VDC)
87215-1110 Repeater between twisted-pair cables
(Power supply: 100 VAC, 200 VAC, 100 VDC)
CP-215 Repeater-TC 87215-1200 Repeater between twisted-pair and coaxial cables
(Power supply: 24 VDC)
CP-215 Repeater-TC
(100 VAC, 200 VAC, 100
VDC)
87215-1210 Repeater between twisted-pair and coaxial cables
(Power supply: 100 VAC, 200 VAC, 100 VDC)
CP-215 Repeater-TP 87215-1300 Repeater between twisted-pair and H-PCF optical fiber cables (850 m)
(Power supply: 24 VDC)
CP-215 Repeater-TP
(100 VAC, 200 VAC, 100
VDC)
87215-1310 Repeater between twisted-pair and H-PCF optical fiber cables (850 m)
(Power supply: 100 VAC, 200 VAC, 100 VDC)
CP-215 Repeater-TS2 87215-1400 Repeater between twisted-pair and crystal optical fiber cables (2 km)
(Power supply: 24 VDC)
CP-215 Repeater-TS2
(100 VAC, 200 VAC, 100
VDC)
87215-1410 Repeater between twisted-pair and crystal optical fiber cables (2 km)
(Power supply: 100 VAC, 200 VAC, 100 VDC)
CP-215 Repeater-TS5 87215-1500 Repeater between twisted-pair and crystal optical fiber cables (5 km)
(Power supply: 24 VDC)
CP-215 Repeater-TS5
(100 VAC, 200 VAC, 100
VDC)
87215-1510 Repeater between twisted-pair and crystal optical fiber cables (5 km)
(Power supply: 100 VAC, 200 VAC, 100 VDC)
