5.6 Relay Function
5-35
5
Remarks
In the example given above, only one Machine Controller that performs network relaying
can be set in each network, as shown under the Remarks for 215IF Network Configuration
2. Therefore, Network Relay is set to
“Yes” only for the following two stations.
• NW#1 ST#1
• NW#2 ST#10
The 215IF uses only one port for the two Machine Controllers ST#6 (NW#1) and ST#15
(NW#2). Therefore, the setting will be Network Relay: Yes.
