5 215IF Module
5.7.5 CP-215 Repeater-TC
5-50
 Repeater-to-Repeater Connector (CN3/B-LINE)
* 1. Refer to System Configuration with Maximum Number of Repeaters
under 5.7.2 System Configuration for the specifications for the maxi-
mum number of Repeaters connected and the total transmission dis-
tance.
* 2. Manufactured by Fujikura Corporation
* 3. Manufactured by Honda Communication Industries Co., Ltd.
 Connector Signal Assignments
* Short-circuiting the RT1 and RT2 terminals connects the internal 75 Ω
terminating resistance.
5.7.5 CP-215 Repeater-TC
The CP-215 Repeater-TC is an electric Repeater that relays CP-215 or CP-216 transmission
signals using coaxial cables.
There are two models of CP-215 Repeater-TC.
• 24-VDC model
• 100/115-VAC, 200-VAC, 100-VDC model
The transmission distance can be extended to a maximum of 100 m.
Item Specifications
Transmission Speed 1 Mbps, 2 Mbps, 4 Mbps (can be set with SW1)
Transmission Distance
*1
500 m between Repeaters (4 Mbps)
Twisted-pair Cable
Inside control panel: YS-IPEV-S (CU), 1P × 0.3 mm
2
, 75 Ω
*2
Outside control panel: YS-IPEV-S (CU), 1P × 1.25 mm
2
, 75 Ω
*2
Applicable Connector
MR-8LM (G)
*3
Transmission Level 68.9 dBm (2.8 Vp)
Reception Level 53.5 dBm (0.475 Vp)
No. Signal Name No. Signal Name
1 SRD- 5
RT2
*
2 Not used 6 Not used
3 Not used 7 Not used
4
RT1
*
8 SRD+
