YASKAWA MP920 - Specifying Detailed Order Patterns

D.6 Optical Cable Specifications
D-37
D
D.6.4 Specifying Detailed Order Patterns
 Optical Fiber Core
 In-panel Cord
Indoor or Outdoor Cable
EG -5 / 1002
Transmission bandwidth (Unit: 100 MHz)
Transmission loss (Unit: 0.1 dB/km)
07: 0.7 dB/km (λ= 1,300 nm)
10: 1.0 dB/km (λ= 1,300 nm)
25: 2.5 dB/km (λ= 850 nm)
30: 3.0 dB/km (λ= 850 nm)
Core diameter (Unit: 10µm)
5: 50µm
Optical fiber type
EG crystal graded fiber
02: 200 MHz
Optical fiber core:
Optical fiber cord: CS EG - 5 / 1002, L-V
Optical fiber core type
Cord sheath material
V: PVC
Signal-core cord
n
Optical fiber cable:
GI - C - 4C - V - NM - SSD (EG - 5 / 1002), L
Optical fiber core type
Special sheath
SSD: Self-supported Cable
MM: Non-metallic type (structure containing no metal)
Blank: Metallic type (structure containing metal)
Indicates the number of cores. Specify this for only
strand structure.
Optical fiber type
GI: Multi-mode fiber core
n: Number of optical fiber cores (1 to 6)
Configuration
C: Cord type (consisting of optical fibers)
L: Stand type (consisting of optical fiber cores.
Only metallic type can be specified.)
GS: Special type (optical fibers protected by GS structure)
Sheath material
V: PVC (indoor)
E: PE (outdoor)
LAP: LAP (outdoor)
