Appendix D Wiring Communications
D.1.2 In-panel Cables
D-12
D.1.2 In-panel Cables
The following table shows the in-panel cables used for communications.
Always use the specified cables. Otherwise, the communications system will fail to provide
its full performance.
When bending a communications cable, be sure that the bending radius is at least 10 times
the finished outer diameter of the cable.
Table D.2 Cable Bending Radius
Communications
System
Cable Type Finished
Outer
Diameter
dl (mm)
Permissible
Bending
Radius
10 dl (mm)
Applicable Duct
215IF,
217IF
RS-485
Twisted-pair cable:
YS-IPEV-SB, 1P × 0.3 mm,
manufactured by Fujikura Cor-
poration
5.6 56 min.
Low-voltage
duct
Twisted-pair cable:
YS-IPEV-SB, 3P × 0.3 mm,
manufactured by Fujikura Cor-
poration
7.2 72 min.
Low-voltage
duct
217IF RS-232C Low-voltage
duct
CP-215
Repeater
Coaxial cable:
3C-2V, manufactured by
Fujikura Corporation
5.6 56 min.
Special-purpose
duct
Coaxial cable:
3C-2V (Cu, Fe) ZV, manufac-
tured by Fujikura Corporation
8.6 86 min.
Low-voltage
duct
218IF Transceiver cable:
DAISET-1581B, manufactured
by Mitsubishi Cable Industries,
LTD.
9.2 100 min.
Low-voltage
duct
