Appendix A System Functions
A.2.5 Outputs
A-20
CH-NO (Channel No.)
CH-NO specifies the channel number of the communications unit. Only one channel number
can be set for the same line.
PARAM (Parameter List Leading Address)
PARAM specifies the leading address of the parameter list. For details on settings, refer to
A.2.3 Parameter Details.
A.2.5 Outputs
BUSY (Processing in Progress)
BUSY indicates that the processing is being executed. Keep EXECUTE set to ON.
COMPLETE (Processing Completed)
COMPLETE is turned ON for only 1 scan upon normal termination.
ERROR (Error Occurred)
ERROR is turned ON for only 1 scan when an error occurs.
For error causes, refer to PARAM00 and PARAM01 described in A.2.3 Parameter Details.
Device Channel No.
215IF
1 to 13
217IF
1
218IF
1 to 10
Serial
1
Applicable
Registers
Leading Address Examples
MW
DW
#W
MA00000, MA00100, …
DA00000, DA00200, …
#A00000, #A00300, …
