D.5 Transmission Line Components
D-29
D
CP-215 Repeater-TC Transmission Line Components
Cables
* Pas4 refers to cable signal dB loss at 4 MHz. Z4 refers to cable character-
istic impedance at 4 MHz.
Note: Specify the desired model and cable length (in 500-m units) when
ordering.
Connectors
Branch Connectors
Name Model Electrical
Product Code
Specifications Usage Manufacturer
Coaxial
Cable
3C-2V
−
Pas4: 25 dB/km
Z4: 75Ω
For in-panel low-voltage
ducts
Fujikura Corpo-
ration
3C-2V(Cu, Fe)-
ZV
−
Pas4: 25 dB/km
Z4: 75Ω
For in-panel low-voltage
ducts
Fujikura Corpo-
ration
5C-2V(Cu, Fe)-
ZV
−
Pas4: 16 dB/km
Z4: 75Ω
For panel-to-panel low-
voltage ducts
Fujikura Corpo-
ration
7C-FB(Cu, Fe)-
ZV
−
Pas4: 10 dB/km
Z4: 75Ω
For panel-to-panel low-
voltage ducts
Fujikura Corpo-
ration
7C-FL(Cu, Fe)-
ZV
−
Pas4: 8.1 dB/km
Z4: 75Ω
For panel-to-panel low-
voltage ducts
Fujikura Corpo-
ration
Name Model Electrical
Product Code
Specifications Usage Manufacturer
BNC
Connector
BNC-P-3-Ni-
CAu
YCN006648 For 3C-2V For use in a control panel Daiichi Elec-
tronic Industries
Co., Ltd.
F-
Connector
FSPW-5-Ni-CAu YCN000144 For 5C-2V For use between control
panels
Fujikura Corpo-
ration
F-7FB YCN000146 For 7C-FB For use between control
panels
Fujikura Corpo-
ration
FSPW-7-Ni-CAu YCN000145 For 7C-FL For use between control
panels
Fujikura Corpo-
ration
Name Model Electrical
Product Code
Specifications Usage Manufacturer
T-Connector BNC-TA-JPJ-Ni-
CAu
YCN006650 For BNC For connection and
branching of 215IF Mod-
ule.
One connector required
for each Module.
Daiichi Elec-
tronic Industries
Co., Ltd.
To Next Page
