Appendix D Wiring Communications
D.5.3 CP-215 Repeater Transmission Line Components
D-30
Conversion Connectors
Junction Connectors
Note: When using a junction connector, wrap self-adhesive tape around the
junction part of the coaxial cable for waterproofing and insulate the
connector to prevent the cable from becoming grounded.
Terminating Connectors
Coaxial Cables with BNC Connector
Name Model Electrical
Product Code
Specifications Usage Manufacturer
Conversion
Adapter
T-0298 YCN005244 Conversion between
BNC and F-connectors
For conversion of in-
panel or panel-to-panel
cable size.
Two adapters required
for each control panel.
DX ANTENNA
CO., LTD.
Name Model Electrical
Product Code
Specifications Usage Manufacturer
Junction
Connector
F-A YCN005279 For connection
between F-connectors
For connection between
panel-to-panel cables
Fujikura Corpo-
ration
Name Model Electrical
Product Code
Specifications Usage Manufacturer
Terminator BNC-RC-75-Ni-
CAu
YCN006647 BNC type, 75Ω, 1 W Mounted at both ends of
transmission line.
Two terminators required
for each transmission
line.
Daiichi Elec-
tronic Industries
Co., Ltd.
Name Model Electrical
Product Code
Specifications Usage Manufacturer
In-panel
Coaxial
Cable
JZMSZ-W60-1
−
3C-2V cable with BNC
connectors at both
ends, 2 m
For use in control panel YASKAWA
ELECTRIC
CORPORA-
TION
To Next Page
