8.2 Connection to a SYSMAC PLC
8-11
8
CN1 and CN2 Cables
Note: OMRON SYSMAC PLC Models:
C20H
C28H
C40H
Note: OMRON PLC Unit Models:
C200H-ASC02
C200H-LK201-V1
C500-LK201-V1
C120-LK201-V1
217IF OMRON PLC
D-sub 9-pin D-sub 9-pin
Signal Name Pin No. Pin No. Signal Name
FG
11
FG
TXD
22
SD
RXD
33
RD
RTS
44
RS
CTS
55
CS
DSR
66
5V
SG
77
SG
N.C.
88
N.C.
DRT
99
N.C.
217IF OMRON PLC
D-sub 9-pin D-sub 25-pin
Signal Name Pin No. Pin No. Signal Name
FG
11
FG
TXD
22
SD
RXD
33
RD
RTS
44
RS
CTS
55
CS
DSR
66
DSK
SG
77
SG
N.C.
88
CD
DTR
920
DTR
Shield
Shield
