A.1 SEND MESSAGE Function (MSG-SND)
A-9
A
The following setting range is used for no-protocol transmissions.
 Remote CPU Number (PARAM07)
Set the remote CPU number.
When the transmission destination is the CP-317, CP-9200SH, or CP-9200, set 1 or 2. When
the destination is the CP-3500H, set 1, 2, 3, or 4. In other cases, set 0.
 Coil Offset (PARAM08)
Set the offset word address of the coils.
This parameter is valid when the function code is 01H, 05H, or 0FH.
 Input Relay Offset (PARAM09)
Set the offset word address of the input relays.
This parameter is valid when the function code is 02H.
 Input Register Offset (PARAM10)
Set the offset word address of the input registers.
This parameter is valid when the function code is 04H or 0AH.
 Holding Register Offset (PARAM11)
Set the offset word address of the holding registers.
This parameter is valid when the function code is 03H, 06H, 09H, 0BH, 0DH, 0EH, or 10H.
31H MELSEC fixed buffer communications Words 1 to 507 (1 to
1FBH)
Not valid. Not valid.
32H MELSEC random buffer read Words 1 to 508 (1 to
1FCH)
Not valid. Not valid.
33H MELSEC random buffer write Words 1 to 508 (1 to
1FCH)
Not valid. Not valid.
(cont’d)
Function
Code
Function Data Address Setting Range
215IF, 218IF 217IF, Serial MECHATROLINK
Data Address Setting Range
217IF 218IF 215IF
No-protocol 1 Words 1 to 254 Words 1 to 510 Words 1 to 510
No-protocol 2 Bytes 1 to 508 Bytes 1 to 1020 Bytes 1 to 1020
