îš„ Visual Aids
The following aids are used to indicate types of information for easier reference.
îš„ Indication of Reverse Signals
In this manual, the names of reverse signals (ones that are valid when low) are written with a
forward slash (/) before the signal name, as shown in the following example:
Indicates important information that should be memorized.
Indicates supplemental information.
Indicates application examples.
Describes technical terms that are difficult to understand, or in the text
without an explanation being given.
• S-ON = /S-ON
• P-CON = /P-CON
IMPORTANT
INFO
EXAMPLE
TERMS
