YASKAWA SGD7S series User Manual

vii

Σ-7-Series
Σ-7S/Σ-7W
SERVOPACK
Product Manuals
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
MECHATROLINK-III
Communications References
Product Manual
SIEP S800001 28
Provide detailed information on
selecting Σ-7-Series SERVO-
PACKs and information on install-
ing, connecting, setting, performing
trial operation for, tuning, and mon-
itoring the Servo Drives.
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
MECHATROLINK-II
Communications References
Product Manual
SIEP S800001 27
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
Analog Voltage/Pulse Train
References
Product Manual
This manual
(SIEP S800001 26)
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK
Command Option Attachable
Type with INDEXER Module
Product Manual
SIEP S800001 64
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK
Command Option Attachable
Type with DeviceNet Module
Product Manual
SIEP S800001 70
Σ-7-Series AC Servo Drive
Σ-7W SERVOPACK with
MECHATROLINK-III
Communications References
Product Manual
SIEP S800001 29

Σ-7-Series
Σ-7S/Σ-7W
SERVOPACK with
Hardware Option
Specifications
Product Manuals
Σ-7-Series AC Servo Drive
Σ-7S/Σ-7W SERVOPACK with
Hardware Option Specifica-
tions
Dynamic Brake
Product Manual
SIEP S800001 73
Provide detailed information on
Hardware Options for Σ-7-Series
SERVOPACKs.
Σ-7-Series AC Servo Drive
Σ-7W SERVOPACK with
Hardware Option Specifica-
tions
HWBB Function
Product Manual
SIEP S800001 72
Continued on next page.
Continued from previous page.
Classification Document Name Document No. Description

YASKAWA SGD7S series Specifications

General

Series	SGD7S
Safety	STO (Safe Torque Off)
Humidity	90% RH or less (non-condensing)
Control Method	PWM Control
Communication	EtherCAT, MECHATROLINK-III, MECHATROLINK-II
Output Power	0.1 kW to 15 kW
Feedback System	Incremental encoder, Absolute encoder
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Overheating, Encoder Error
Ambient Temperature	0 to 55°C
Storage Temperature	-20 to 85°C
Vibration Resistance	5.9 m/s²
Installation	Panel mounted
Certifications	CE, UL, cUL
