YASKAWA SGD7S series User Manual

viii
Σ-7-Series
Σ-7S/Σ-7W SERVOPACK
FT/EX
Product Manuals
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
FT/EX Specification for Index-
ing Application
Product Manual
SIEP S800001 84
Provide detailed information on the
FT/EX Option for Σ-7-Series
SERVOPACKs.
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
FT/EX Specification for Track-
ing Application
Product Manual
SIEP S800001 89
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
FT/EX Specification
for Application with Special
Motor,
SGM7D Motor
Product Manual
SIEP S800001 91
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with FT/EX
Specification for Press and
Injection Molding
Product Manual
SIEP S800001 94
Option Module
User’s Manual
AC Servo Drives
Σ-V Series/Σ-V Series
for Large-Capacity Models/
Σ-7 Series
User’s Manual
Safety Module
SIEP C720829 06
Provides details information
required for the design and mainte-
nance of a Safety Module.
Enclosed Documents
AC Servo Drive
Rotary Servomotor
Safety Precautions
TOBP C230260 00
Provides detailed information for
the safe usage of Rotary Servomo-
tors and Direct Drive Servomotors.
AC Servomotor
Linear Σ Series
Safety Precautions
TOBP C230800 00
Provides detailed information for
the safe usage of Linear Servomo-
tors.
Σ-7-Series
Servomotor
Product Manuals
Σ-7-Series AC Servo Drive
Rotary Servomotor
Product Manual
SIEP S800001 36
Provide detailed information on
selecting, installing, and connecting
the Σ-7-Series Servomotors.
Σ-7-Series AC Servo Drive
Linear Servomotor
Product Manual
SIEP S800001 37
Σ-7-Series AC Servo Drive
Direct Drive Servomotor
Product Manual
SIEP S800001 38
Σ-7-Series
P
eri
pheral Device
Selection Manual
Σ-7-Series AC Servo Drive
Peripheral Device
Selection Manual
SIEP S800001 32
Describes the peripheral devices
for a Σ-7-Series Servo System.
Continued on next page.
Continued from previous page.
Classification Document Name Document No. Description

YASKAWA SGD7S series Specifications

General

Series	SGD7S
Safety	STO (Safe Torque Off)
Humidity	90% RH or less (non-condensing)
Control Method	PWM Control
Communication	EtherCAT, MECHATROLINK-III, MECHATROLINK-II
Output Power	0.1 kW to 15 kW
Feedback System	Incremental encoder, Absolute encoder
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Overheating, Encoder Error
Ambient Temperature	0 to 55°C
Storage Temperature	-20 to 85°C
Vibration Resistance	5.9 m/s²
Installation	Panel mounted
Certifications	CE, UL, cUL
