YASKAWA SGDV-OCA05A

15.1 List of Parameters
15.1.2 List of Parameters
15
Parameter Lists
15-21
Pn52B 2 Overload Warning Level 1 to 100 1% 20 All
Immedi-
ately
Setup
page
5-38
Pn52C 2
Base Current Derating
at Motor Overload
Detection
10 to 100 1% 100 All
After
restart
Setup
page
5-39
Pn530
2
Program Jogging-
Related Selections
0000h to
0005h
−
0000h All
Immedi-
ately
Setup
page
7-13
Pn531 4
Program Jogging Travel
Distance
1 to
1,073,741,824
1 refer-
ence
unit
32768 All
Immedi-
ately
Setup
page
7-13
Pn533 2
Program Jogging Move-
ment Speed
1 to 10,000
Rotary:
1 min
-1
Direct
Drive:
0.1
min
-1
500 Rotary
Immedi-
ately
Setup
page
7-13
Pn534 2
Program Jogging Accel-
eration/Deceleration
Time
2 to 10,000 1 ms 100 All
Immedi-
ately
Setup
page
7-13
Pn535 2
Program Jogging Wait-
ing Time
0 to 10,000 1 ms 100 All
Immedi-
ately
Setup
page
7-13
Pn536 2
Program Jogging Num-
ber of Movements
0 to 1,000 Times 1 All
Immedi-
ately
Setup
page
7-13
Pn550 2
Analog Monitor 1 Offset
Voltage
-10,000 to
10,000
0.1 V 0 All
Immedi-
ately
Setup
page
9-11
Pn551 2
Analog Monitor 2 Offset
Voltage
-10,000 to
10,000
0.1 V 0 All
Immedi-
ately
Setup
page
9-11
Pn552 2
Analog Monitor 1 Mag-
nification
-10,000 to
10,000
× 0.01 100 All
Immedi-
ately
Setup
page
9-11
Pn553 2
Analog Monitor 2 Mag-
nification
-10,000 to
10,000
× 0.01 100 All
Immedi-
ately
Setup
page
9-11
Pn55A 2
Power Consumption
Monitor Unit Time
1 to 1,440 1 min 1 All
Immedi-
ately
Setup
−
Pn560 2
Residual Vibration
Detection Width
1 to 3,000 0.1% 400 All
Immedi-
ately
Setup
page
8-56
Continued on next page.
Continued from previous page.
Parameter
No.
Size
Name
Setting
Range
Setting
Unit
Default
Setting
Applicable
Motors
When
Enabled
Classi-
fication
Refer-
ence
n.X
Program Jogging Operation Pattern
0
(Waiting time in Pn535 → Forward by travel distance in Pn531) × Number of
movements in Pn536
1
(Waiting time in Pn535 → Reverse by travel distance in Pn531) × Number of
movements in Pn536
2
(Waiting time in Pn535 → Forward by travel distance in Pn531) × Number of
movements in Pn536
(Waiting time in Pn535 → Reverse by travel distance in Pn531) × Number of
movements in Pn536
3
(Waiting time in Pn535 → Reverse by travel distance in Pn531) × Number of
movements in Pn536
(Waiting time in Pn535 → Forward by travel distance in Pn531) × Number of
movements in Pn536
4
(Waiting time in Pn535 → Forward by travel distance in Pn531 → Waiting time
in Pn535 → Reverse by travel distance in Pn531) × Number of movements in
Pn536
5
(Waiting time in Pn535 → Reverse by travel distance in Pn531 → Waiting time
in Pn535 → Forward by travel distance in Pn531) × Number of movements in
Pn536
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
