15.1 List of Parameters
15.1.2 List of Parameters
15-22
Pn561 2
Overshoot Detection
Level
0 to 100 1% 100 All
Immedi-
ately
Setup
page
8-30,
page
8-40
Pn581 2 Zero Speed Level 1 to 10,000 1 mm/s 20 Linear
Immedi-
ately
Setup
page
1-8
Pn582 2
Reserved parameter
(Do not change.)
−−
10 Linear
−−−
Pn583 2
Brake Reference Out-
put Speed Level
0 to 10,000 1 mm/s 10 Linear
Immedi-
ately
Setup
page
5-30
Pn584 2
Speed Limit Level at
Servo ON
0 to 10,000 1 mm/s 10000 Linear
Immedi-
ately
Setup
page
8-9
Pn585 2
Program Jogging Move-
ment Speed
1 to 10,000 1 mm/s 50 Linear
Immedi-
ately
Setup
page
7-13
Pn586 2
Motor Running Cooling
Ratio
0 to 100
1%/
Max.
speed
0Linear
Immedi-
ately
Setup
−
Pn587 2
Reserved parameter
(Do not change.)
−−
0000h Linear
−−−
Pn600 2
Regenerative Resistor
Capacity
*2
Depends on
model.
*3
10 W 0 All
Immedi-
ately
Setup
page
5-52
Pn601 2
Dynamic Brake Resis-
tor Allowable Energy
Consumption
0 to 65,535 10 J 0 All
After
restart
Setup
*4
Pn603 2
Regenerative Resis-
tance
0 to 65,535 10 mΩ 0All
Immedi-
ately
Setup
page
5-52
Pn604 2
Dynamic Brake Resis-
tance
0 to 65,535 10 mΩ 0All
After
restart
Setup
*4
Pn61A
2
Overheat Protection
Selections
0000h to
0003h
− 0000h Linear
After
restart
Setup
page
6-35
Pn61B
*6
2 Overheat Alarm Level 0 to 500 0.01 V 250 All
Immedi-
ately
Setup
page
6-36
Pn61C
*6
2 Overheat Warning Level 0 to 100 1% 100 All
Immedi-
ately
Setup
page
6-36
Pn61D
*6
2
Overheat Alarm Filter
Time
0 to 65,535 1 s 0 All
Immedi-
ately
Setup
page
6-36
Pn621 to
Pn628
–
Reserved parameters
(Do not change.)
−−−
All
−−−
PnB01
2Origin Return Direction
0000h and
0001h
−
0001h All
Immedi-
ately
Setup
page
12-4
Continued on next page.
Continued from previous page.
Parameter
No.
Size
Name
Setting
Range
Setting
Unit
Default
Setting
Applicable
Motors
When
Enabled
Classi-
fication
Refer-
ence
n.

X Overheat Protection Selection
0 Disable overheat protection.
1
Use overheat protection in the Yaskawa Linear Servomotor.
*5
2
Monitor a negative voltage input from a sensor attached to the machine and
use overheat protection.
3
Monitor a positive voltage input from a sensor attached to the machine and
use overheat protection.
n.

X

Reserved parameter (Do not change.)
n.

X

Reserved parameter (Do not change.)
n.X

Reserved parameter (Do not change.)
0000h Forward
0001h Reverse
