5.3 C: Tuning
YASKAWA ELECTRIC SIEP C710616 30B YASKAWA AC Drive T1000A Technical Manual 151
Parameter Details
5
n C5-25: Motor 2 ASR Limit
Functions for motor 2 in the same way that C5-05 functions for motor 1. Sets the ASR output limit for motor 2 as a
percentage of the maximum output frequency (E4-04). For more details, see C5-05: ASR Limit on page 149.
n
C5-26: Motor 2 ASR Primary Delay Time Constant
Functions for motor 2 in the same way that C5-06 functions for motor 1.
Sets the filter time constant for the time from the speed loop to the torque command output. For more details, see C5-06:
ASR Primary Delay Time Constant on page 149.
Note: This parameter rarely requires adjustment.
n C5-27: Motor 2 ASR Gain Switching Frequency
Functions for motor 2 in the same way that C5-07 functions for motor 1.
Sets the frequency for motor 2 to change ASR proportional gain 1 and 2 (C5-21, C5-23) as well as the integral time 1 and
2 (C5-22, C5-24). For more details, see C5-01, C5-03 / C5-02, C5-04: ASR Proportional Gain 1, 2 / ASR Integral Time
1, 2 on page 148.
Note: A multi-function input set for the ASR gain switch (H1- = 77) takes priority over the ASR gain switching frequency.
n C5-28: Motor 2 ASR Integral Limit
Functions for motor 2 in the same way that C5-08 functions for motor 1.
Sets the upper limit for ASR as a percentage of the rated load.
n
C5-32: Integral Operation during Accel/Decel for Motor 2
Functions for motor 2 in the same way that C5-12 functions for motor 1.
Enables integral operation during acceleration and deceleration. For more details, see C5-12: Integral Operation during
Accel/Decel (V/f w/PG) on page 150.
Setting 0: Disabled
Integral operation occurs only during constant speed and not during acceleration or deceleration.
Setting 1: Enabled
Integral operation is always enabled.
n
C5-37, C5-38: Motor 2 Inertia, Motor 2 Load Inertia Ratio
These parameters function for motor 2 in the same way that C5-17 and C5-18 function for motor 1.
No. Parameter Name Setting Range Default
C5-21
<1> The setting range is 1.00 to 300.00 in CLV.
Motor 2 ASR Proportional Gain 1
0.00 to 300.00
<1> Determined by E3-01
C5-22
Motor 2 ASR Integral Time 1
0.000 to 10.000 s Determined by E3-01
C5-23 Motor 2 ASR Proportional Gain 2 0.00 to 300.00 <1> Determined by E3-01
C5-24 Motor 2 ASR Integral Time 2 0.000 to 10.000 s Determined by E3-01
No. Parameter Name Setting Range Default
C5-25 Motor 2 ASR Limit 0.0 to 20.0% 5.0%
No. Parameter Name Setting Range Default
C5-26 Motor 2 ASR Primary Delay Time Constant 0.000 to 0.500 s 0.004 s
No. Parameter Name Setting Range Default
C5-27 Motor 2 ASR Gain Switching Frequency 0.0 to 400.0 Hz 0.0 Hz
No. Parameter Name Setting Range Default
C5-28 Motor 2 ASR Integral Limit 0 to 400% 400%
No. Parameter Name Setting Range Default
C5-32 Integral Operation during Accel/Decel for Motor 2 0, 1 0
