Zebra DS6878 - Time Delay to Presentation Sleep Mode (continued)

528 pages

To Next Page

To Next Page

To Previous Page

To Previous Page

Loading...

5 - 26 DS6878 Product Reference Guide

Time Delay to Presentation Sleep Mode (continued)

15 Minutes

(27)

30 Minutes

(29)

45 Minutes

(30)

*1 Hour

(33)

3 Hours

(35)

6 Hours

(38)

9 Hours

(41)
