Symbologies 15 - 75

GS1 DataBar

The variants of GS1 DataBar are DataBar-14, DataBar Expanded, and DataBar Limited. The limited and

expanded versions have stacked variants. Scan the appropriate bar codes to enable or disable each variant of

GS1 DataBar.

GS1 DataBar-14

Parameter # 338

GS1 DataBar Limited

Parameter # 339

*Enable GS1 DataBar-14

(1)

Disable GS1 DataBar-14

(0)

Enable GS1 DataBar Limited

(1)

*Disable GS1 DataBar Limited

(0)

NOTE For HC configurations, the default is Enable.
