CHAPTER 12 SCANNER EMULATION

INTERFACE

This chapter provides instructions for programming the cradle to interface with a digital scanner emulation

host. With digital scanner emulation, the cradle connects either to an external decoder or to a decoder

integrated in a portable terminal or Point-of-Sale (POS) terminal.

Throughout the programming bar code menus, default values are indicated with asterisks (

*).

*Parameter Process

and Pass-Through

Feature/Option

* Indicates Default
