C - 4 DS6878 Product Reference Guide

GS1 DataBar-14

PDF417

Data Matrix

55432198673467

(GS1 DataBar-14 Truncated)

90876523412674

(GS1 DataBar-14 Stacked)

78123465709811

(GS1 DataBar-14 Stacked Omni-Directional)
