7 - 4 DS6878 Product Reference Guide
USB Parameter Defaults
Table 7-1 lists the defaults for USB host parameters. If any option needs to be changed, scan the appropriate
bar code(s) provided in the Parameter Descriptions section beginning on page 7-5.
NOTE See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 7-1 USB Host Default Parameters
Parameter Default
Page
Number
USB Host Parameters
USB Device Type USB Keyboard (HID) 7-5
Symbol Native API (SNAPI) Status Handshaking Enable 7-7
USB Country Keyboard Types (Country Codes) North American 7-8
USB Keystroke Delay No Delay 7-10
USB CAPS Lock Override Disable 7-10
USB Ignore Unknown Characters Send 7-11
USB Convert Unknown to Code 39 Disable 7-11
Emulate Keypad Disable 7-12
Emulate Keypad with Leading Zero Disable 7-12
Quick Keypad Emulation Disable 7-13
USB FN1 Substitution Disable 7-13
USB Static CDC Enable 7-14
Function Key Mapping Disable 7-14
Simulated Caps Lock Disable 7-15
Convert Case No Case Conversion 7-15
Beep Directive Honor 7-16
Bar Code Configuration Directive Honor 7-16
USB Polling Interval 8 msec 7-17

Zebra DS6878 Specifications

General

Wavelength	655 nm
Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	1D, 2D, PDF417, PDF417, microPDF417, Composite Codes (CC-A, CC-B, CC-C), U.S. Postnet and Planet, U.K., Japan, Australian, Netherlands KIX code, Royal Mail 4 State Customer, UPU ICS 4 State Postal, USPS 4CB, TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse and Micro)
Tilt reading angle	-360 - 360 °
Input voltage	5 V
Bluetooth	Yes
Dimensions (WxDxH)	69 x 97 x 185 mm
Certification	FCC, RoHS
Product color	Black
International Protection (IP) code	IP43
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Cables included	USB

Weight and Dimensions

Weight	238 g
