Zebra DS6878 - I 2 of 5 Reduced Quiet Zone

To Next Page

To Previous Page

15 - 52 DS6878 Product Reference Guide

I 2 of 5 Reduced Quiet Zone

Parameter # 1210

Scan one of the following bar codes to enable or disable decoding I 2 of 5 bar codes with reduced quiet zones.

If you select Enable, select a 1D Quiet Zone Level on page 15-93.

Enable I 2 of 5 Reduced Quiet Zone

(1)

*Disable I 2 of 5 Reduced Quiet Zone

(0)
