Zebra DS6878 - FN1 Substitution; Send Make and Break

To Next Page

To Previous Page

Keyboard Wedge Interface 9 - 11

FN1 Substitution

When enabled, the digital scanner replaces FN1 characters in an EAN128 bar code with a keystroke chosen

by the user (see FN1 Substitution Values on page 5-50).

Send Make and Break

When enabled, the scan codes for releasing a key are not sent.

Enable FN1 Substitution

*Disable FN1 Substitution

*Send Make and Break Scan Codes

Send Make Scan Code Only
