Zebra DS6878 - GS1 QR; MicroQR

To Next Page

To Previous Page

Symbologies 15 - 87

GS1 QR

Parameter # 1343

To enable or disable GS1 QR, scan the appropriate bar code below.

MicroQR

Parameter # 573

To enable or disable MicroQR, scan the appropriate bar code below.

Enable GS1 QR

(1)

*Disable GS1 QR

(0)

*Enable MicroQR

(1)

Disable MicroQR

(0)
