Sample Bar Codes C - 3

GS1 DataBar

NOTE GS1 DataBar variants must be enabled to read the bar codes below (see GS1 DataBar on page 15-75).

10293847560192837465019283746029478450366523

(GS1 DataBar Expanded Stacked)

1234890hjio9900mnb

(GS1 DataBar Expanded)

08672345650916

(GS1 DataBar Limited)
